Important characteristics

  • Temperature range: -40 °C to 180 °C
  • APT.line™ preheating chamber technology
  • Programmable condensation protection for test material
  • Heated viewing window with LED interior lighting
  • BINDER Multi Management Software APT-COM™ Basic Edition
  • Troubleshooting system with visual and audible alarms
  • Intuitive touchscreen controller with time-segment and real-time programming
  • Internal data logger, measured values can be read out in open format via USB
  • Access port with silicone plug, 50 mm, left
  • Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm
  • 4 castors, two with brakes
  • Computer interface: Ethernet
  • 230 V power socket on the right-side control panel
  • Adjustable ramp function
  • Integrated chart recorder
  • Real-time clock
  • Door heating
  • 1 stainless steel rack
  • Inner chamber made of stainless steel
  • CFC-free refrigerant R-452A
  • Cooling with compressor cooling unit

General Specifications

Designation

MK240-400V¹

MK240-480V-C¹

Option model

Standard

with voltage and frequency converter

Order number

9020-0376

9020-0355

Performance Data Temperature

Average cooling down time according to IEC 60068-3-5 [K/min]

4.5

4.5

Average heating-up rate according to IEC 60068-3-5 [K/min]

5

5

Cooling down time from 180 °C to -40 °C [min]

110

110

Max. heat compensation at 25 °C [W]

2000

2000

Temperature fluctuation depending on setpoint [± K]

0.1…0.5

0.1…0.5

Temperature range [°C]

-40…180

-40…180

Temperature variation depending on setpoint [± K]

0.1…1.2

0.1…1.2

Electrical data

Nominal power [kW]

5.6

5.6

Phase (Nominal voltage)

3~

3~

Power frequency [Hz]

50

60

Rated Voltage [V]

400

480

Unit fuse [A]

16

16

Doors

Unit doors

1

1

Housing dimensions not incl. fittings and connections

Depth net [mm]

925

925

Height net [mm]

1710

1710

Width net [mm]

1115

1115

Internal Dimensions

Depth [mm]

443

443

Height [mm]

700

700

Width [mm]

735

735

Measures

Interior volume [L]

228

228

Load per rack [kg]

30

30

Net weight of the unit (empty) [kg]

340

340

permitted load [kg]

70

70

Viewing window height [mm]

300

300

Viewing window width [mm]

508

508

Wall clearance back [mm]

300

300

Wall clearance sidewise [mm]

200

200

Environment-specific data

Sound-pressure level [dB(A)]

62

67

Fixtures

Number of shelves (std./max.)

1/6

1/6

  1. All technical data is specified for unloaded units with standard equipment at an ambient temperature of +22 °C ±3 °C and a power supply voltage fluctuation of ±10 %. The temperature data is determined in accordance to BINDER factory standard following DIN 12880, observing the recommended wall clearances of 10 % of the height, width, and depth of the inner chamber. Technical data refers to 100 % fan speed. All indications are average values, typical for units produced in series. We reserve the right to change technical specifications at any time.
