Vision Engineering Camβ - Handheld Digital Magnifier

Loading...

Vision Engineering Camβ - Handheld Digital Magnifier

Product Information:

Camβ

Camβ digital magnifier, has been designed especially for applications where viewing, image capture, reporting and documentation is needed. Magnify, inspect and capture images where you want, when you want.

  • Magnification up to 20x
  • LED Illumination
  • Store up to 20,000 images

What can I use it for?

  • Roaming magnification tasks
  • Inspection of hard to reach places
  • Periodic inspection tasks
  • Fault documentation
  • Serial number identification
  • Training aid
  • Low vision magnifier

Camβ (Cam Beta) digital inspection magnifier is ideal for roaming inspectors, documenting faults, or for inspecting immobile subjects. With a high resolution colour display, easy button operation, simple image capture and download, you can inspect & capture quickly and simply.

It can be used in hard to reach areas, such as high up inside large machines as well as remote locations to access wild flowers and insects. This portable electronic magnifier can also be easily stored and transported for access when needed. Making it extremely suitable for production environments.

Highlights

  • Highly flexible & portable
  • Fast and accurate image capture
  • 4.3” colour display with dimension grid
  • Virtual caliper display with movable filar lines
  • Live view via mini-HDMI output
  • Can be used for all sorts of roamng inspection tasks
  • Controllable LED Illumination optimised for magnified imaging
  • Store up to 20,000 images

Why Camβ is better than your smartphone

Unlike a digital camera, Camβ’s 4 LED illumination is optimised for magnified imaging, so you can see the subject clearly and evenly illuminated.

To facilitate viewing objects where reflections may be an issue, the lighting can be cycled through four settings. The brightness of the LED’s can also be adjusted to optimise viewing.

Advantages:

  • Optics optimised for close working
  • Illumination configured for close working
  • Image security (no connection to Wifi)
  • Live HDMI TV-out
  • Secure grip for left and right hand use

Stability leg

The Camβ is provided with a flip out leg to aid stability at high magnification which is located around the lens on the underside. Simply flip it out fully to help maintain the ideal distance from the item you are viewing. Click it back in place when not in use.

Industrial and production applications

Camβ portal digital magnifier is great for documenting faults and inspection of immobile subjects. It is very useful when inspectiing electronics, such as cable connections within broadband cabinets.

Camβ is well suited in production environments. It is handy for inspection subjects in dark or hard to reach areas. Also ideal in secure environments where company's policy disallows the use of mobile phones. Simple operation allows for quick parts documentation and /or training and quality assurance.

Medical related applications

From inspection of sterilised medical equipment to medical devices, Camβ offers a convenient way of meeting critical inspection and documentation requirements.

Dental prosthetics need to be tailored for each individual person and often requires inspection and image documentation for quality purposes. Other dental uses include smile evaluation for cosmetic dental consultation.

Typical applications include automotive, aviation, watchmaking, general manufacturing as well as a low vision magnification aid.

Inspect where you want, when you want......

More Information
General Specifications
Technical
Display4.3"
View modes
  • Full colour
  • Black & white
  • Inverted black & white
  • Grey scale
Magnification4x, 8x, 16x and 20x
Illumination
  • 4 x LED, optimised for magnified imaging.
  • 4 Level settings: 100%, 75%, 50%, 25%
Dimension grids
  • Yes, fixed 1mmgrid lines
  • Simple X,Y on-screen dimensioning
  • Virtual caliper
MeasurementYes (inch/mm)
Image capture resolution1280 x 720, JPEG
Video outMini-HDMI TV-out
Connections
  • Micro USB connection for image download and charging
  • Mini-HDMI for monitor
BatteryLithium ion, 6 hour continuous operation time
Dimensions283mm (l) x 88mm (h) x 22mm (d)
Weight205g
Number of stored images20,000
Internal memory4 GB
Kit contentsCamβ, soft case, USB cable, mini-HDMI-HDMI cable, TV out cable, Lanyard, cleaning cloth, user guide
Write Your Own Review
You're reviewing:Vision Engineering Camβ - Handheld Digital Magnifier
Your Rating
Customer Questions
Can I measure with the Camβ Handheld Digital Magnifier?

Yes, the Camβ has a measurement function that can take simple measurements quickly. It is a very simple function to apply.

How good is the battery life in the Camβ Handheld Digital Magnifier?

The battery life for the Vision Engineering Camβ lasts for approximately 6 hours, with standard settings. Adjusting brightness of the screen could allow you to get slightly more time out of a full charge.

What does the Camβ Handheld Digital Magnifier come with upon delivery?

There are several elements that come with the kit for the Camβ. These include:

  • The Camβ itself
  • Soft Case for the unit
  • USB Cable
  • Mini-HDMI – HDMI cable
  • TV out Cable
  • Lanyard
  • Cleaning Cloth
  • User manual

Can I use the Camβ for training purposes?

The Camβis ideal for training purposes. The supplied HDMI cable allows you to connect directly to a monitor. You can then share images with ease to demonstrate and train individuals at your whim.
