An high definition digital microscope with stunning image quality, that combines optical excellence with ease of use and efficient workflows. EVO Cam II makes image capture and documentation simpler, faster and more reliable.

  • Exceptional high resolution 1080p/60fps image quality
  • Optical magnification up to 300x
  • Stand alone, wireless or PC connectivity

Stunning images. Exceptional simplicity

Now with Extended functionality!

EVO Cam II digital microscope delivers excellent image quality to help uncover hidden details. Optical excellence and magnification up to 300x ensures ultra-sharp images at all times, EVO Cam II is optimised for quality control, testing, inspection and documentation.

Leading optical performance makes EVO Cam II a supremely powerful imaging solution with a range of objective lens options to ensure stunning results for any application. Exceptional simplicity minimises training requirement, making EVO Cam II a powerful and flexible tool, ideal for multiple users and production environments.

EVO Cam II’s new firmware extends the functionality, and further builds confidence and consistency of inspection and increases the flexibility of the system through functionality.

  • NEW: Calibration tracking with zoom
  • NEW: Customisable zoom range
  • NEW: Image comparison
  • NEW: Image playback
  • NEW: Supervisor settings lock
  • NEW: Focus stacking in camera

Ease of use

Simplicity of use is fundamental to EVO Cam II. Easy to follow menu and simple operation minimizes training needs and is an ideal solution for multiple users in fast paced production environments.

Save and recall settings at the push of a button with EVO Cam II presets. Help texts, available in any of 10 preloaded languages, means users can take guidance in their preferred language.

In addition to the convenient operation of all main functions on the unit, a remote control console allows faster and more comfortable use.

Ultra-sharp live images

High-quality optics used in EVO Cam II has specialist coatings providing the best optical output, consistency and performance for many industrial applications.

EVO Cam digital microscope for pcb inspection

  • New focus stacking feature adds extended depth of focus to subjects that are too deep to be captured in a single image. Subjects up to 110mm can be captured full in focus.
  • Auto (and manual) focus, with auto control of other camera settings (white balance, exposure, brightness) ensures ultra-sharp, high contrast imaging at all times.
  • View more detail in shadows and highlights with Wide Dynamic Range (WDR). Ideal for high contrast subjects, such as reflective metals.
  • Fast high speed frame rate (60fps) camera ensure video images are super smooth without juddering.

New! Focus stacking

Focus stacking shows subject images with extra depth of field by layering multiple images with different focus positions. The layers are presented so that the in-focus areas are combined to create a single in-focus image. Stack images of subjects up to 110mm deep.

Image capture without focus stacking

*Image capture without focus stacking

Image capture with focus stacking

*Image capture with focus stacking

Shadow-free illumination

Integral 8-point LED ring light ensures optimum shadow-free illumination for all applications. Colour temperature 5500K.

Transmitted substage illumination permits viewing of a wider range of sample types.

Image Transfer

Images can easily be captured and saved from the EVO Cam II directly to a USB dongle at the touch of a button.

Alternatively they can be transferred securely to a computer via cable output (HDMI or USB 3.0) or wireless using a Wi-Fi dongle. Using a Wi-Fi dongle removes the need for extra cabling and allows the user to quickly view and download images and videos, making it ideal when access for multiple users is required.

Revealing more detail with 360° rotating viewer

This unique feature offers a full 360° rotating view without the need to move the subject under magnification, making inspection easier and quicker.



360 degree inspection

The 34° angle allows detail to be seen at the base of any vertical component or feature. Operators can simply switch between rotating oblique view and a direct view for ultimate flexibility.

Simple on-screen measurement

EVO Cam II includes easy on-screen measurement capability, with selectable overlays, grid and cursors.

Simple measurement

Easy calibration and innovative calibration tracking means setup is easy and reliable measurements are available at the push of a button. Removing the need to recalibrate at each zoom position.

Cursor mode displays two movable horizontal and vertical lines, allowing measurement of X and Y values with results displayed on screen. Also point to point diagonal measurement allows measurement of non-aligned items.

Calibrated grids can be displayed, scaled and positioned as required.

Customisable overlays are easily created and quickly imported into the camera allowing easy comparison against drawings, samples or reticules.


Stand Options

The modular design of EVO II Cam enables the user to select from a wide variety of stand options, illumination and accessories.

Multi-axis stand

  • Precise and robust, ideal for industrial applications where maximum work space is desired.
  • Integrated gas strut provides counter-balanced adjustability, making operation quick and effortless. Switch between tall components and flat samples with ease.
  • Available with platform base, or mounted directly to the work surface.

Ergo stand

  • Small footprint providing exceptional stability for high magnification use.
  • Transmitted substage illumination (option) permits viewing of a wider range of sample types.
  • Floating stage (option) provides sensitive control, to accurate inspection of samples; ideal for inspecting fragile samples, or for avoiding contamination by handling.

Double-arm boom stand

  • Designed specifically for applications requiring extended reach, without compromising stability.
  • Easy adjustability allows precise positioning and alignment.
  • Available with platform base, or with clamp for mounting directly to the work surface



Articulated arm stand

  • Designed for applications requiring extended reach, with ultimate flexibility.
  • Multi-point adjustability allows precise positioning and alignment.



Single-arm boom stand

  • High stability boom stand, ideal for larger specimens.
  • Cost-effective stand option, complete with heavy duty platform base.



Bench stand

  • Compact unit with low-profile base and integral transmitted substage illumination.
  • Floating stage (option) provides sensitive control for accurate inspection of samples.

Accessories

The modular design of EVO Cam allows tailoring for many individual application requirements.

Remote control console

In addition to convenient operation of all main functions. Remote control allows ergonomic operation preventing need to reach up to the head. Additionally it has 3 hotkey buttons for quick access to three most desired ‘Presets’.

Objective lenses

A range of objective lens options ensure stunning results for any application, whether for high magnification, high precision detail work, or for manipulation, re-work, or assembly tasks requiring an extra-long working distance.

Objective lenses incorporate anti-reflection coatings to enhance imaging performance and a filter thread.

Floating stage

  • A floating stage option provides smooth and precise control, ideal for inspecting fragile samples and for avoiding contamination by excessive handling.
  • For use with Ergo stand and Bench stand only.

Transmitted substage illumination

  • Transmitted substage illumination permits viewing of a wider range of sample types. Provides flexibility as transparent samples can be viewed by transmitted as well as reflected light.

360° rotating viewer

  • The ultimate inspection accessory, permitting a full 360° rotating view of the subject (at an angle of 34° from the vertical).
  • The 360° rotation provides enhanced observation for many applications, including electronics (PCB solder joints, holes, pillars and thread forms), mechanical, medical and plastics components.
  • Easily switch between 360° rotating view and a direct view for ultimate convenience.
  • Includes integrated 8-point LED ring light and objective lens .

Filters

There are a range of filters available, to enhance details within subjects not easily seen by the human eye.

UV ring light

The UV ring light is an excellent optional accessory for EVO Cam II. It is suitable for many applications ranging from electronics, aerospace and forensics.
View FileEVO Cam II brochure    Size: (1.15 MB)

General Specifications

To discuss your particular requirements in further detail, please contact us.

Objective lenses

A range of objective lens options ensure stunning results for any application, whether for high magnification, high precision work, or for manipulation, re-work, or assembly tasks requiring an extra-long working distance.

Precision objective lenses

Ultra-high resolution and contrast, optimized for precision magnification work, with anti-reflective coating and filter thread.

Precision objective lenses
Objective lens 0.45x 0.62x 1.0x 1.5x 2.0x
Magnification zoom range 2.3x – 68x 3.1x – 93.7x 5x – 151.2x 7.6x – 226.8x 10x – 302.4x
Working distance 6.30″(160mm) 4.17″ (106mm) 3.35″ (85mm) 1.69″ (43mm) 1.14″ (29mm)
Field of view at max. zoom 0.31″ x 0.17″ (7.8mm x 4.2mm) 0.22″ x 0.12″ (5.5mm x 3.1mm) 0.14″ x 0.08″ (3.5mm x 2mm) 0.09″ x 0.05″ (2.3mm x 1.2mm) 0.06″ x 0.04″ (1.5mm x 1mm)
Filter thread 49mm 55mm 49mm None None

Wide-field objective lenses

Wide field of view, suited for larger subjects. An extra-long working distance provides maximum flexibility, with anti-reflective coating and filter thread.

Wide-field objective lenses
Objective lens 4 diopter 5 diopter
Magnification zoom range 1.75x – 51.4x 2.1x – 65.5x
Working distance 9.65″ (245mm) 7.76″ (197mm)
Field of view at max. zoom 0.39″ x 0.22″ (10mm x 5.5mm) 0.31″ x 0.18″ (8mm x  4.5mm)
Filter thread 52mm 52mm

Camera

Leading specification optical performance makes EVO Cam a supremely powerful imaging solution.

Camera data
Camera zoom 30x optical; 12x digital
Camera resolution Full-HD 1080p, 1920 x 1080, 1/2.8″ CMOS
Frame rate 50fps & 60fps (switchable)
Focus Auto focus and manual focus
Output HDMI & USB 3.0
Saved file type .png

360° rotating viewer (option)

360° rotating view
Zoom ratio 5.3:1
Zoom range 19x – 105x
Working distance 35.5mm
Field of view at min. zoom 25.7mm x 22.1mm
Field of view at max. zoom 2.6mm x 2.2mm
Viewing angle 34° from vertical
Direct view
Zoom ratio 5.3:1
Zoom range 28x – 151x
Working distance 56.5mm
Field of view at min. zoom 19.7mm – 11.2mm
Field of view at max. zoom 1.6mm – 0.9mm
Viewing angle

Illumination

  • Integral 8-point LED ring light ensures optimum shadow-free illumination for all applications. Colour temperature 5500K.
  • Transmitted substage illumination (option) permits viewing of a wider range of sample types.

EVO Cam on-board controls

  • Zoom in/out
  • Ring light illumination control
  • Secondary illumination control, e.g. transmitted substage illuminator (if fitted)
  • Image capture
  • Overview mode
  • Focus: Auto/manual
  • White balance: Auto
  • Image brightness
  • Infra-red filter: On/off
  • Wide Dynamic Range (WDR) mode
  • Presets and hotkeys
  • On-screen display: On/off (to display magnification)
  • Crosshair: size/color
  • Calibration
  • Cursor/Grid/Overlay
  • Imperial/metric units
  • Sound on/off

Remote control console

All EVO Cam II on-board controls can be accessed via the remote control console option. Additional functionality of the remote control console option allow fast access to the 3 presets.

Power supply

  • Standard power 100V-240V, 50/60Hz, available in all worldwide plug configurations.

Connections

  • HDMI (monitor output)
  • USB 3.0 (PC output)
  • USB 2.0 x 2 (memory stick, remote console or Wi-Fi dongle)
  • PSU Jack
  • External ring light jack
  • Transmitted substage jack

Dimensions

Multi-axis stand

EVO Cam Multi-axis stand dimensions
  • A = 455mm (184mm*)
  • B = 635mm (830mm**)
  • C = 691mm max.
  • D = 279mm max. (less working distance)
  • E = 439mm max.* without platform base. ** maximum depth with arm overhang.

Ergo stand

EVO Cam Bench stand dimensions
  • A = 280mm
  • B = 420mm
  • C = 515mm
  • D = 192mm max. (less working distance)
  • E = 200mm

Double-arm boom stand

EVO Cam Double-arm boom stand dimensions
  • A = 250mm (168mm*)
  • B = 827mm
  • C = 543mm (424mm*)
  • D = 334mm (232mm*) max. (less working distance)
  • E = 655mm max.* without platform base.

Single-arm boom stand

EVO Cam Single-arm boom stand dimensions
  • A = 278mm
  • B = 587mm – 625mm
  • C = 485mm
  • D = 220mm max. (less working distance)
  • E = 430mm max.

Articulated arm stand
EVO Cam Articulated arm stand dimensions
  • A = 168mm
  • B = 1140mm max.
  • C = 812mm max.
  • D = 519mm max. (less working distance)
  • E = 812mm max.
  • F = 305mm (removable)

Bench stand

EVO Cam Bench stand dimensions
  • A = 240mm
  • B = 285mm
  • C = 340mm
  • D = 117mm max.
  • E = 85mm




Accessories

  • Remote control console
  • Objectives
  • Filters
  • 360° rotating viewer
  • Floating stage
  • Transmitted substage illumination (standard with Bench stand, option with Ergo stand)
