- Two ionizing air guns can be connected at the same time
- Ion balance: around ±10V, neutralize static charges rapidly.
- Stable ion balance, adjust outside, easy operation.
- Built-in silencer, low noise.
- Capacitor coupling high voltage design, safe and reliable.
|Supply Voltage 220V AC 50Hz/60Hz
High Voltage Output 7KV(-40%-0)
Sub short-circuit Current 3mA
Rated Power 30Watt
Neutralize static voltage to 10V or below within 10 seconds.
Neutralize Requirement: 300mm away from front panel with largest air volume.
Time for Static Neutralizing:
Air Pressure Distance 15cm 30cm 45cm 60cm
0.2M pa Decay time(s) 0.9s 1.3s 1.7s 2.1s
1.0s 1.4s 2.1s 2.9s
Ion balance(V) -1V +5V +6V 0V
0.4M pa Decay time(s) 0.8s 1.0s 1.3s 1.9s
1.0s 1.3s 2.0s 2.5s
Ion balance(V) 0V +1V +1V 0V
0.6M pa Decay time(s) 0.8s 1.0s 1.4s 1.5s
0.9s 1.4s 1.8s 2.7s
Ion balance(V) -2V -4V +6V -14V
Ambient conditions: 22, Relative Humidity 60-70%.
Test as per ANSI/EOS/ESD-S3.1- 1991 standard.
Neutralizing time from 1000V to 10V and ion balance voltage
