Apollo Seiko L-CAT NEO Soldering Robot


Apollo Seiko L-CAT NEO Soldering Robot


This is the next generation robot which has all the functions necessary for selective soldering built into the machine. The L-CAT NEO has been designed for either an in-line or lean manufacturing process. A data management is available for PC communication, smart phone (IPhone, IPAD, Android) and mobile equipment.


We have over 40 years of results and experience as a soldering robot supplier.  Our application knowledge and customer requirements have made us stronger than our competitors.


X, Y, Z and ZR axes are the all including X axis, are available the easy designing fixture and conveyer layout. Heavy work and long length work are no problem for the L-CAT NEO because there is no need to move the fixture. Moreover, this is available to the in-line and cell production.


Normally soldering robots are fixed sequence.  However, “L-CAT NEO” has a highly flexible soldering sequence that can be customized to meet the needs of your specific application.  The L-CAT NEO offers flexibility for customization of parameters for applications which require high thermal energy as well as fine pitch devices.


The robot management to the computer is now taken as a matter of course, you’re smart phone can communicate to the robot. The performance is becoming the name of next generation robot.


  • Available for Windows 7 (32, 64 bit) and Windows XP
  • Can manage multiple robots for Ethernet
  • Data logging to the robot’s state. Saved as csv file type
  • Sends/Receives and edit and save teaching data

Teaching and data management used on iPhone, iPad, Android and Windows smartphones.

More Information
General Specifications
Drive Method Stepping Motor
Encoder 4-axes applicable
Resolution (X,Y,Z Axes) 0.01mm
Resolution (R Axis) 0.1°
Portable Weight 6kg
Axis Speed (X,Y Axes) Max: 1200mm/sec - Min: 0.1mm/sec
Axis Speed (Z Axis) Max: 320mm/sec - Min: 3.2mm/sec
Axis Speed (R Axis) Max: ±800°/sec - Min: 8°/sec
Repeatability (X,Y,Z Axes) ±0.01mm
Repeatability (R Axis) ±0.02°
Teaching Methods Remote Teaching (Jog)
Manual Data Input (MDI)
External Input/Output Input: 39 - Output: 39
Program Capacity 511 programs
Memory Capacity 500,000 point
Setting Temparature 0~500℃
Solder Feeding Speed 1.0~50.0mm/sec
Solder Feeding Amount Resolution 0.1mm
Solder Diameter With ZSB Feeder φ0.4~φ1.0mm(Option: φ0.3,1.2,1.6mm)
Solder Diameter With Normal Feeder φ0.3~φ1.6mm
Heater Capacity 130W (Option: 200W available)
Nitrogen Generator Standard equipment to robot, included with digital flow meter
Display Language English, Chinese, Korean, Japanese
Power Source AC94~260V (Single Phase)
Power Consumption 650W max
Other Equipped With Monitoring Camera


Operation Range (X,Y,Z Axes)

L-CAT NEO-N4330 300 x 300mm
L-CAT NEO-N4430 400 x 300mm
L-CAT NEO-N4530 500 x 300mm


Dimensions & Weight

Dimensions WxDxH (mm)
L-CAT NEO-N4330 690 x 686 x 800
L-CAT NEO-N4430 790 x 686 x 800
L-CAT NEO-N4530 890 x 686 x 800
Weight (kg)
L-CAT NEO-N4330 90
L-CAT NEO-N4430 95
L-CAT NEO-N4530 100
