All Dr. Storage cabinets comply with J-STD-033B and have two or more drying modules, so that regeneration of drying media is automatic. Drying modules can be mixed and matched, and replaced in the field. QDA or Quick Dry Air modules are used as supplemental dryers to bring the humidity level down quickly and to add positive pressure inside the Dry Box. QDA dryers need compressed air for operation. Turbo dryers are high efficiency forced convection dryers. Also available are QDN or Quick Dry Nitrogen modules, which add positive internal pressure using nitrogen. These nitrogen-equipped models can be used alone or in conjunction with Turbo dryers to conserve nitrogen.

Features

All Dr. Storage Humidity Control Storage Systems Have These Features:

  • Turbo dry modules for faster drying
  • Serial port for data recording
  • Data recording management software
  • Antistatic package
  • Locking wheels & door for security
  • Adjustable shelves
  • Automatic Alarm light

How does it work?

How Dr. Storage Products will improve your manufacturing yield:

  • 1. Dry Storage: moisture sensitive SMD packages exposed in the air should be stored in Dr. Storage X2E or T40 series for resetting the floor life. For example: if MSD parts of MSD Level 4, 5 and 5a are exposed for less than eight hours, they can be stored in a dry cabinet for resetting the floor life. However, if their exposure time is longer than eight hours, the SMD packages should be stored at 40Ì´åÁX in a T40 Baking Dry Box to reset the floor life.
  • 2. Alarm Hygrometer: The temperature and humidity of the production line should be kept stable. Adapt an Alarm Hygrometer HT-5B or HT-1B to alert the engineers. Futhermore the centralized network monitor function can help engineers to manage 32 sets Alarm Hygrometer at a PC.
  • 3. Data Recording: It is important to verify that the condition of storage complies with the J-STD-033B. The user can connect laptop computer directly to the RS232 port of the cablnet to acquire the data or use our data logger to record the data. With our data recording function, the historical fluctuation of relative humidity and temperature can be shown clearly in the graph.
  • 4. The floor life of the Moisture Sensitive Devices can also be calculated in the software. This uniquely patented function can easily verify if the SMD packages are stored at proper condition. It is very convenient for those who carry out quality assurance procedures.

Applications

Dr. Storage is ideal for all these applications:

  • Storing & drying ICs prior to placement.
  • Drying and storing multilayer PCBs, either before or after placement.
  • Humidity-free storage of film and other materials used in PCB fabrication.
  • Effective prevention of oxidation of PCBs stored for bottom-side mounting after completion of topside mounting.
  • Desiccant automatically regenerates, thus desiccant level is continuously maintained.
  • Contamination-free even drying at room temperature of washed LC glass boards.
  • Humidity-free storage of quartz crystals and electrode adhesives used in the manufacture of quartz oscillators.
  • Dry storage of moisture-absorbing materials (epoxy resins, chemicals and adhesives).
  • Low humidity storage of electronic components to prevent oxidation.
View FileKaisertech Product Guide v.2.o    Size: (5.76 MB)

General Specifications

Model X2E-600

  • Electrical Requirements: 230V
  • External Size: 610mm w x 1.82m h x 711mm d
  • Internal Size: 596mm w x 1.64m h x 660mm d
  • Internal Capacity : 0.65 cu mtrs
  • No. of Shelves : 5 Adjustable
  • Shelf adjustability : On 30 cm centers
  • Data Logger : Optional
  • Data Reader : Optional
  • Data Software : Included
  • Nitrogen Dry Modules (QDN) : Optional

ModelX2B-200-BINX2B-400-BINX2B-600-BINX2B-1200-6-BIN
RH Range ≤5% RH
Internal Capacity (cu ft) 6 12 21 44
Internal Capacity (L) 202 413 624 1,250
External Size (in)
WxDxH
23.6 x 26.5 x 24.9 23.6 x 26.5 x 50.2 23.6 x 26.5 x 71.5 47.2 x 26.5 x 24.9
External Size (mm)
WxDxH
600 x 672 x 632 600 x 672 x 1275 600 x 672 x 1815 1200 x 672 x 1815
Internal Size (in)
WxDxH
23.5 x 25.3 x 20.7 23.5 x 25.3 x 42.1 23.5 x 25.3 x 64.0 47.2 x 25.3 x 64.0
Internal Size (mm)
WxDxH
598 x 642 x 525 598 x 642 x 1070 598 x 642 x 1625 1198 x 642 x 1625
No. of Adjustable Shelves 2 3 5 5
Shelf adjustability 30 mm
Levellers/Wheel Levellers Levellers and 4 wheels
Electrical Requirements Standard - 110VAC
230VAC - Opt.
Data Software N/A
Data Network N/A
SMS Text alarm to cell phone N/A
Component Rack for Reels Optional
Data Logger N/A
Data Reader N/A
Applications Electronic components and printed circuit boards
