GXA 450-H Shut-Off Brushless Spindle | Remote Start | 1-4.41Nm
GXA 450-H Shut-Off Brushless Spindle | Remote Start | 1-4.41Nm
The GX 450-H fixtured spindle is equipped with a maintenance-free brushless motor. It has a fast chuck type drive for 1/4 female hex bits and a lever/push start. Being an electric shut-off spindle, it can perform your automated assemblies with precision.
It features advanced setting functions such as digital speed adjustment electronics or soft start.
Simple to integrate into your production workspace thanks to a mounting flange. The tool can be locked remotely by your automation and you have the choice of rotation direction.
Features Of The GX 150-H Spindle
- Higher productivity thanks to high brushless motor efficiency
- Higher comfort with improved ergonomy and reduced sound level & heat
- Increased economy thanks to motor
- Reduced maintenance
- Increased production quality with ESD protection
- Noise level: <70 dBA, vibration level: <2,5 m/s²
Benefits Of The GX-H Series
Productivity - Maximum efficiency at high rotation speeds. Reliable with optimised features and protection against surge and temperature overloads.
Quality - Unmatched cost efficiency, with a start, reversibility, and non-contact sensor shut off. Built to last with an ESD-free casing and maintenance-free brushless motor.
Comfort - Light and ergonomic in the hand, simple for long-term use. The weight to ergonomic ratio has been perfected, along with the silent motor than operates under 70 dBA.
Other Versions
Version | Torque Range (Nm) |
GXA 150-H | 0.3-1.47 |
GXA 220-H | 0.6-2.15 |
GXA 450-H | 1-4.41 |
GXA 150P-H | 0.3-1.47 |
GXA-220P-H | 0.6-2.15 |
GXA 450P-H | 1-4.41 |
