The standard in the laboratory, ideal for a wide range of applications for Inductry 4.0.
Industry 4.0
The integrated KERN Universal Port (KUP) allows the connection of external KUP interface adapters such as RS-232, USB, Bluetooth, WLAN, Analogue, Ethernet etc. The advanatge with this is that the KUP interface adapters are simply plugged in, i.e retrofitting interfaces is conveniently possible without opening the scale housing or complicated installation.
The interface adapters enable convenient transmission of weighing data to networks, PCs, smartphones, tablets, laptops, printers etc.
Additionally, control commands and data inputs can also be sent to the scale via the connected devices.
Overall Dimensions (without draught shield):
WxDxH 163x245x65mm
Key Features:
- PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
- Recipe function - Can weigh the different ingredients of a mixture. You can also call up the total weight of all ingredients
- Weighing with tolerance range (check-weighing): a visual signal helps with portioning, dispending or grading
- Freely programmable weighing unit, e.g. display direct in special units
- A special Anti-Shock system between the weighing plate and weighing; reduces vibrations during the weighing process and ensures rapid, reliable weighing results.
Weighing Plate/Surface Dimensions & Materials:
| Weighing Plate | Dimensions Weighing Surface | Weighing Plate Material |
| A | ∅ 82mm | Plastic, with conductive lacquer |
| B | ∅105mm | Stainless steel |
| C | WxD 130x130mm | Stainless steel |
| D | WxD 150x170mm | Stainless steel |
See the KERN PCB In Action Below:
Other Variations:
| Model | Weight Capacity [MAX] (g) |
| PCB 200-3 | 200 |
| PCB 300-3 | 360 |
| PCB 300-2 | 300 |
| PCB 1000-2 | 1200 |
| PCB 3000-2 | 3600 |
| PCB 2000-1 | 2000 |
| PCB 6000-1 | 6000 |
| PCB 10000-1 | 10000 |
| PCB 6000-0 | 6000 |
