Quick 861DW Hot Air Rework Station 1000W

£240.00 (exc VAT) (£288.00 inc VAT)

Was: £265.00 Save £25.00

Quick 861DW 1000W Hot Air Rework Station

Zoom Out
Zoom In

Product Information:

  1. Three regular channels are "CH1", "CH2" and "CH3". Each channel's parameters including temperature and airflow can be set.
  2. Password protection and key-lock functions.
  3. Real time operation by the magnetic switch. It will enter sleeping state when the handle is placed on holder.
  4. Auto sleeping function. Parameters can be set in sleeping state.
  5. Closed loop sensor. Temperature can be controlled by zero voltage triggering modes, and adjusted conveniently, accurate and stable, not affected by airflow.
  6. Large power, rapid heating.
  7. A multipurpose unit, having brushless whirlpool motor, wide range and stepless adjustable airflow.
  8. An automatic cooling system can prolong the life time of heating element and protect the handle.
  9. The Quick 861DW includes 3 nozzles; 4mm, 6.4mm and 8.4mm.

Product Composition:

  • 1 x 861DW Hot Air Rework Station
  • 1 x Holder for hot air handle
  • 1 x UK plug
  • 3 x Straight nozzles ( as pictuered above )

Choosing your 861:

The 861 comes in 2 variants - the DE and DW.

The DE version has a 1200w heater and 200L air flow, and the DW version has a 1000w heater with 120L air flow.

Compared to the older DA model, the DE and DW feature an updated handpiece with a Quick Change nozzle.

This allows for quick and easy changing of the nozzle, where the DA required a tool to remove the nozzle.

(optional) Angled Nozzle Pack:

  • Add this to your order by selecting the pack on the drop down menu on the right side of the page.
  • Quick Angled Nozzle's compatible with 861DE and 861DW
  • Includes 6.4, 8.4 and 12.7mm angled nozzles
  • Perfect for Micro Soldering
View FileQuick 861 Nozzles    Size: (522.22 KB)
View File861 Manual    Size: (647.11 KB)

General Specifications

Power 1000W
Voltage 220V 50/60HZ
Temperature Range 100℃-500℃
Airflow Range 1-120
Max Airflow 120L/min
Size (L*D*H) 188(L)*245(D)*135(H)mm
Weight  3.65kg
Nozzles Supplied: 3x Straight Nozzles (image below)

861DW Hot Air Station
