Zestron Vigon RC303 RTU
Reflow oven cleaner
VIGON® RC 303 was specifically developed to remove all types of baked-on flux residues from reflow and wave solder equipment. It reliably removes re-condensed fluxes and emissions from assemblies. The medium does not contain any ingredients which could leave residues on the oven surfaces. This avoids harmful condensation on the assembly surfaces after restarts
As the successor to VIGON® RC 101, VIGON® RC 303 delivers an improved cleaning performance with the same high level of operator safety.
Advantages compared to other soldering furnace cleaners:
- Improved cleaning performance
- Mild formulation, high operator safety
- No flash point
- Environmentally friendly
- No special labeling is required
- Little odor
- Excellent material compatibility with aluminum and epoxy surfaces
Advantages compared to other cleaning agents:
Higher cleaning quality and process reliability
o Improved cleaning performance
o The medium does not contain any ingredients which could leave residues on the
oven surfaces. This avoids harmful condensation on the assembly surfaces after
o Excellent material compatibility with aluminum and epoxy surfaces
o No flash point
o High operator safety
o Environmentally friendly
o No special labeling is required
o Little odor
More efficient cleaning process to avoid long machine downtimes
o Short soaking time due to advanced formulation
o Can be applied directly onto cold or warm surfaces (20 - 50 °C / 68 - 122 °F)
o Also suitable for the pre-cleaning of condensation traps
|Vigon RC 303 Size: (257.54 KB)|
Density (g/ccm) at 20°C/68°C 1,01
Surface tension (mN/m) at 25°C/77°F 31,8
Boiling range °C/°F > 99/ > 210.2
Flash point °C/°F None
pH-value 10g/l H2O 10.1
Vapor pressure (mbar) at 20°C/68°F Approx. 22
Cleaning temperature °C/°F 20 – 50 / 68 – 122
Solubility in water Soluble
Application concentration Ready-to-use Pure
HMIS Rating Health/Flammability/Reactivity 0 – 0 – 0
Extensively tested and suitable for
cleaning of lead-free solder pastes
Product is free of any critical
substances according to SIN &
100% compliance with EU
guidelines (RoHS 1 & 2, WEEE)
Environmental, health and safety regulations:
RC 303 is water-based and biodegradable.
RC 303 is formulated free of halogenated compounds and is very
environmentally friendly and considered a non-hazardous material.
No special precaution for handling VIGON®
RC 303 is required.
RC 303 is available as a ready-to-use solution in 1l spray bottles, 5l or 25l
containers and 200l drums.
RC 303 in the original container at a temperature between
5 - 30 °C / 41 - 86 °F.
The product has a minimum shelf life of 5 years in factory sealed containers.
Alternative product recommendation:
For dip-tank cleaning of removable oven parts, i.e. condensation traps or solder frames,
we recommend ATRON® SP 200, ATRON® SP 300 or ATRON® SP 400.
This also applies for extremely baked-on residues.
